LG DLE2515S DLG2525S TD V10062G Dryer Service Manual

Description

This original service manual for the LG DLE2515S DLG2525S TD V10062G dryer sets out the manufacturer’s diagnostic approach and repair instructions for the models named on this product page.

Manual Specifications

• Manufacturer: LG
• Models: DLE2515S DLG2525S TD V10062G
• Appliance: Dryer
• Publication: Original manufacturer service manual
• Pages: 41

Instant Download

The service documentation is supplied digitally for immediate access after purchase.

Manual Contents

• Specifications: Sets out the dryer specifications for checking the appliance against its intended operating configuration.
• Features and Benefits: Introduces the operating features that form the background to the service procedures.
• Installation Instructions: Sets out installation procedures and connection requirements for checking the dryer’s initial setup before diagnosing faults.
• Dryer Cycle Process: Traces the dryer cycle, giving context for a programme that stops or fails to progress normally.
• Component Testing Information: Sets out tests used to evaluate dryer components before deciding on further repair work.
• Motor Diagram and Schematic: Shows the motor circuit and schematic connections for tracing the drive system during electrical diagnosis.
• Control Layout: Shows the control layout as a reference when checking selections and interpreting dryer operation.
• Wiring Diagram: Provides the electrical wiring reference used to trace connections during diagnosis and repair.
• Diagnostic Test: Details the diagnostic procedure, including checks for the thermistor, moisture sensor, door switch, motor, electric-version heater switch, gas-version valve.
• Change Gas Setting (Natural Gas, Propane Gas): Explains the specified gas-setting change between natural gas and propane for the documented gas version.
• Disassembly Instructions: Details how the dryer is dismantled to access the assemblies discussed in the diagnostic sections.
• Exploded View: Illustrates the relationships between dryer assemblies and components for identifying their position during dismantling and reassembly.

Common Problems Covered

For the LG DLE2515S DLG2525S TD V10062G, use the documented diagnostics to investigate cycle or component faults. The wiring reference supports electrical fault tracing, while the component tests and dismantling instructions help connect the symptoms with the next service check.

Technician Reference

Consult the component checks before dismantling the dryer, then use the access instructions to reach the assemblies involved in the repair.

Who Is This Manual For?

Appliance repairers can follow the documented tests and dismantling instructions. Owners can use the same publication to understand manufacturer-guided troubleshooting and keep an accessible technical record of their dryer.
